HIGH-THRUST FOR LOW-SPEED OPERATION
X-SERIES HIGH-THRUST
X-HT: Power Where It Matters Most
Unparalleled power at low speeds: Introducing the MJP X-HT, the high-thrust variant of our
acclaimed X-Series waterjets. Engineered for maximum performance at low and medium
speeds, the MJP X-HT is ideal for demanding commercial and industrial applications.
Well known and proven X-Series Design
Building on the trusted X-Series design, the X-HT waterjet delivers proven performance optimized for low-speed applications, ensuring reliability and familiarity for your next project.
High-thrust
The X-HT jets delivers more thrust compared to other jets in the same range and is optimized for efficiency at slow speed and high bollard pull capabilities
Minimal Inboard Footprint
The X-HT series boasts a compact design that allows for larger diameter jets to be installed in narrower hulls, optimizing performance without compromising space
Input Power
The lower-input power capability of the X-HT ensures it remains lightweight and cost-effective to operate, crucial for the efficiency and sustainability of wind farm operations
Duplex Stainless Steel Pump Construction
Our duplex stainless steel pump has been expertly engineered to be the most efficient and durable pump ever built
MAX KW / MAX BHP
611 kW - 1000 kW
819 bhp - 1341 bph
Materials
- Body
- Aluminum
- Pump Unit
- Duplex Stainless Steel
- Intake
- Aluminum
For Vessels
12-40m
Marine Jet Power’s X-HT waterjets are built for demanding operations like crew transfers and offshore work. Optimized for low to medium speeds (up to 35 knots), they deliver strong thrust at slow speeds-perfect for wind farm CTVs and other workboats. The compact design allows for larger jets in narrow hulls, while low input power keeps weight and fuel use down for efficient, sustainable performance.
Made from duplex stainless steel, Marine Jet Power jets offer industry-leading strength and corrosion resistance. Integrated steering and DPO ensure precise control and easy station keeping during loitering, loading, or docking-so you and your crew can stay on schedule, safely and
For Vessels That
Operate at Low-Speed
Increased Bollard Pull
High Thrust
Smaller Footprint
Optimized Efficiency at Slow Speed
Specifications
Where technology meets reality
| Model | Dry Weight | Intake | KW | A | B | C | D | E | F | G | H | I |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 280X-HT | 650 kg | 140 L | 611 | 1175 | 980 | 808 | 400 | 1148 | 1497 | 796 | 965 | 0° |
| 310X-HT | 880 kg | 200 L | 800 | 1319 | 1102 | 859 | 450 | 1218 | 1671 | 880 | 1086 | 0° |
| 350X-HT | 1124 kg | 280 L | 1000 | 1466 | 1225 | 991 | 500 | 1282 | 1842 | 964 | 1207 | 0° |
500X Power in a 350X Body
Where technology meets reality
Enhanced Thrust and Efficiency
The X-HT jets delivers more thrust compared to other jets in the same range and is optimized for efficiency at slow speeds. This makes the X-HT particularly well-suited for vessels operating in and around wind farms, where precise maneuvering and consistent power are essential.
Space-Saving Design
The compact design allows for larger diameter jets to be fitted into narrower hulls, maximizing thrust without requiring extensive modifications to the vessel’s structure.
Range of Sizes and Power Ratings
The X-HT is currently available in three sizes, the 280 X-HT, 310 X-HT, and 350 X-HT, with maximum power ratings of 611 kW, 800 kW, and 1000 kW respectively. This range of options ensures that there is a suitable model for a variety of vessel types and operational requirements.
Environmentally Friendly
Low-power operation reduces fuel consumption and emissions.
350X-HT compared to the 500X
