HIGH-THRUST FOR LOW-SPEED OPERATION
X-SERIES HIGH-TRUST
Built for X-Speed
This completely re-imagined waterjet is ushering in a new era of water propulsion performance. You asked for speed and we delivered the X-Series. With an optimized mixed flow pump capable of speeds in excess of 50 knots, buckle up. Built from duplex stainless steel, this unit is stronger, lighter, more efficient, and more corrosion resistant to keep you on the water and moving faster when every second counts. With the all new redesigned cast aluminum reversing bucket and optimized intake, you’ll be stopping on a dime and performing lightning fast maneuvers like a cheetah on the hunt. Seatbelts not included.
NEW STEERING FIN DESIGN
The new hydrodynamically designed steering fin gives superior responsiveness and steering efficiency
ENHANCED REVERSING BUCKET
The cast aluminum bucket has been designed to improve stopping distance and increase maneuverability. And its new narrow design minimizes center-to-center placement on multiple jet installs
NTERCEPTOR INTEGRATION
The interceptor placement maximizes stagnation pressure under the hull, generating greater lift. Additional interceptors can be fitted on either side of the jet
MIXED-FLOW DUPLEX STAINLESS STEEL PUMP
Proven with more than 18 million running hours, our stainless steel, mixed flow pump has been expertly engineered to be the most efficient and durable pump ever built
OPTIMIZED INTAKE GEOMETRY
The superior high-speed characteristics of the pump allows optimized intake at lower speeds, thereby developing optimal performance over the complete speed range, without impacting top-speed capabilities
INTEGRATED HYDRAULIC SYSTEM
The all inboard integrated hydraulic system provides superior corrosion resistance and eliminates the risk of external oil spills. Featuring separated seals for water and oil, the X Series is compliant with clean-water regulatory requirements
MAX KW / MAX BHP
611 - 2070 kW
819 - 2776 bhp
Materials
- Body
- Aluminum
- Pump Unit
- Duplex Stainless
- Intake
- Steel Aluminum
For Vessels
12-40m
Specifications
For Vessels 12m-26m
Bolt on Installation
Cast Aluminum Intake
Hydro-Mechanical Controls Available
| Model | Dry Weight | Intake | KW | A | B | C | D | E | F | G | H | I |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 280 X | 370 kg* | 47 L | 611 | 1154 | 686 | 717 | 280 | 984 | 1270 | 520 | 699 | 0° |
| 310 X | 425 kg* | 72 L | 800 | 1185 | 758 | 750 | 310 | 1106 | 1458 | 550 | 770 | 3° |
| 350 X | 615 kg* | 106 L | 1000 | 1403 | 857 | 902 | 400 | 1140 | 1689 | 620 | 901 | 0° |
For Vessels 20m-40m
Fabricated Aluminum Intake
Full Classification Approval
PTO Driven Hydraulic Pump
| Model | Dry Weight | Intake | KW | A | B | C | D | E | F | G | H | I |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 400 X | 880 kg* | 171 L | 1327 | 1177 | 980 | 850 | 400 | 1541 | 2132 | 830 | 965 | 0° |
| 450 X | 1170 kg* | 243 L | 1680 | 1492 | 1102 | 942 | 450 | 1704 | 2380 | 910 | 1086 | 0° |
| 500 X | 1516 kg* | 349 L | 2070 | 1660 | 1225 | 1067 | 500 | 1895 | 2665 | 1040 | 1207 | 0° |
References
Where Performance Meets Precision.
-
Marell M17 Hybrid Electric Interceptor
The Marell M17 Hybrid Electric Interceptor represents the cutting edge of maritime performance and sustainable propulsion.
-
DEARSAN USV SALVO
The Dearsan USV Salvo is a high-speed unmanned surface vessel (USV) powered by dual MJP 310 and MJP X-Series waterjets.
